2009 Moto Guzzi Griso 8V

Moto Guzzi Griso 8VGriso 8V2009 Griso 8VMoto Guzzi Griso

His power was increased both by the fact itself and in public opinion”. This quote from “I promessi sposi” by Alessandro Manzoni, refers to Griso, the head of a group known as the “Bravi” “to whom the most dangerous jobs were entrusted”. This refers to the character of the new Griso 8V that is the smartest and most high spirited Moto Guzzi ever made and that encompasses an absolute new sense of “Sporting spirit” stemming from the power and technology of the innovative “Quattrovalvole” engine. Although designed along traditional lines, the new engine features 563 brand new components and is a celebration of the logic behind the 90° V concept. It features a single overhead camshaft per head that operates the four valves on each cylinder with noiseless timing chains. This is quite an evolution of the 1200 cc engine that, with its 75% of its components renewed, now puts out 110 CV at 7,500 rpm with maximum torque of 11 kgm at 6,400 rpm.

The power delivery is silky smooth and on the open road the bike’s true sports character shines along with the countless technical innovations and the new sense of style. Although the exclusive exhaust system with twin coiled pipes has been seen before, it now truly reflects the greater power of these machines. From the looks point of view, the Griso 8V has undergone customising that includes particular stylistic details like the new saddle and streamlined bodywork as well as equipment levels of the highest possible level. Even the most discerning of palates will appreciate the front end with its Brembo P4/34 radial caliper brakes that act on wave floating discs measuring Ø 320mm.

They will also delight in the Showa upside-down forks that have had 43 layers of carbon nitride treatment. Sitting astride the bike, the rider can immediately appreciate the sports riding position that the new setup between handlebars, saddle and footpegs provides. These are all new components and were specially designed to make the rider feel completely in control. The two-seater saddle creates a superb rear view and there seems to be a tail like on a single seater. In fact there is more than enough room for a passenger to sit in great comfort. Powerful, elegant and exclusive, the Griso 8V will soon become an icon among those who truly appreciate elite motorcycles. The Griso is offered in three colour schemes: Jet Black, Moon White and Corsa Red.

Engine

  • Type :Four-stroke V 90 twin Cooling :Air and oil cooled with independent cooling pump
  • Capacity :1,151cc
  • Bore and stroke :95 x 81.2 mm
  • Compression ratio :11 : 1
  • Timing diagram :Intake valve opening 36° before upper TDC. (play 1 mm) Intake valve closing 62° after lower TDC. Exhaust valve opening 58° before lower TDC. Exhaust valve closing 30° after upper TDC. measured with rocker arm/valve play of 1.5 mm
  • Maximum power output :Over 80.8 kW (110 CV) at 7,500 rpm
  • Max Torque :Over 108 Nm at 6,400 rpm
  • Fuel supply/ignition :Multipoint sequential electronic injection, Magneti Marelli IAW 5A phased, alfa-n system; 2 x Ø50 mm throttle bodies with Weber IWP 189 injectors, Lambda probe.
  • Starter :Electric
  • Spark plugs :NGK PMR8B (Long Life)
  • Exhaust system :Stainless steel two-into-one 3-way catalysed with Lambda probe. Homologation :Euro 3

Transmission

  • Gearbox :6 speed
  • Gear ratios :1st 17/38 = 1 : 2.235 :2nd 20/34 = 1 : 1.700 :3rd 23/31 = 1 : 1.348 :4th 26/29 = 1 : 1.115 :5th 31/30 = 1 : 0.968 :6th 29/25 = 1 : 0.862
  • Lubrication :Oil bath
  • Primary drive :Helicoidal gears, ratio 26/35 = 1 : 1.346
  • Final drive :CA.R.C reactive drive; double universal joint with floating bevel gear, ratio 12/44 = 1 : 3,666
  • Clutch :Single plate with integrated flexible couplings

Frame

  • Frame :High tensile steel tubular twin cradle
  • Wheelbase :1,554 mm
  • Rake :108 mm
  • Steering rake :26.30°
  • Steering angle. :34°
  • Front suspension :Upside down Ø 43 mm fully adjustable forks (spring preload and hydraulic for rebound and compression) with mounting for radial calipers. Front wheel travel :120 mm
  • Rear suspension :Progressive single swingarm, fully adjustable monoshock with separate gas reservoir (spring preload and hydraulic for rebound and compression).
  • Rear wheel travel :110 mm
  • Front brakes :Twin floating 320 mm stainless steel wave discs, radial calipers with 4 opposed pistons.
  • Rear brakes :Single 282 mm fixed stainless steel disc, floating caliper with 2 parallel pistons.
  • Wheels :Three-spoked aluminium alloy
  • Front wheel :3.50” x 17”
  • Rear wheel :5.50” x 17”
  • Front tyre :120/70 ZR17”
  • Rear tyre :180/55 ZR17”

Electrics

  • Voltage :12 V
  • Battery :12 V – 18 Ah
  • Alternator :12 V – 550 W

Dimensions

  • Length :2,260 mm
  • Width :830 mm
  • Height :1,070 mm
  • Saddle height :800 mm
  • Minimum ground clearance :185 mm
  • Dry weight :222 kg
  • Fuel tank capacity :16.7 litres
  • Reserve :3.3 litres
